P0204: Injector Circuit Open - Cylinder 4? Here's What You Need to Know

Look - if you're getting a P0204 code, you're dealing with an injector circuit problem for cylinder 4. This means the engine control module (ECM) isn't getting the proper signals from the fuel injector. Instead of throwing parts at it, let's break down what this really means and how to fix it without wasting your time or money.

This code often shows up when there's a fault in the wiring, the injector itself, or the ECM. If you've noticed rough idling or poor acceleration, you're likely feeling the effects of a cylinder not firing properly. Before you rush into replacing parts, let's troubleshoot this issue step-by-step.

Symptoms

  • Rough idling or stalling
  • Decreased fuel efficiency
  • Check Engine Light illuminated
  • Engine misfire, especially under load
  • Loss of power during acceleration
  • Increased emissions
  • Unusual engine noises

Diagnostic order

  1. Inspect the wiring and connector for cylinder 4 injector for damage or corrosion. Look for short circuits and broken connections.
  2. Check the injector resistance with a multimeter. It should typically be around 12-16 ohms for most fuel injectors. If it's out of this range, replace the injector.
  3. Test the power supply to the injector while the engine is running. You should see around 12V when the injector is activated.
  4. Inspect the ECM for any programming issues or faults. Make sure it’s functioning correctly.
  5. Finally, if all else checks out, consider replacing the fuel injector for cylinder 4.

Common questions

1. What causes a P0204 code?

This code is caused by an open circuit in the injector circuit for cylinder 4, which could be due to wiring issues, a faulty injector, or an ECM problem.

2. How can I tell if the injector is bad?

Check the resistance with a multimeter. If it’s outside the normal range (12-16 ohms), or if it doesn’t activate when power is supplied, it likely needs replacing.

3. Is this a common issue across all vehicles?

No, it varies. Some engines are more prone to injector issues, like the Ford EcoBoost and GM Ecotec engines.

4. Can I drive my car with a P0204 code?

Yes, but it’s not advisable. Driving with a misfire can lead to further damage, especially to the catalytic converter.

5. How much will it cost to fix?

Costs can vary widely, but generally expect $100-$400 depending on whether you need to replace wiring, connectors, or the injector itself.

6. Will a bad fuel pump cause this code?

Not directly, but low fuel pressure can lead to injector performance issues. Always check fuel pressure first.

7. Do I need to reset the check engine light after repairs?

Yes, after fixing the issue, use an OBD2 scanner to clear the code. If the repairs were successful, the light shouldn't come back.

8. Are there any specific vehicle quirks I should be aware of?

Yes, some platforms may have known issues that can trigger this code more easily, such as the Honda K-series engines experiencing injector harness faults.

Vehicle-specific notes

  • Ford EcoBoost (1.5/2.0/2.3/3.5L): Look for chafed wiring in the engine harness.
  • Honda K-series (2.0/2.4): Injector connectors can corrode, causing intermittent issues.
  • GM 2.4 Ecotec: These are known for injector harness failures due to heat exposure.
  • Chrysler 3.6 Pentastar: Be cautious of oil leaks that can affect the injector wiring.
  • BMW N20/N54/N55: Check for water intrusion in the injector connectors.
  • VW/Audi 2.0T TSI: Common to have injector issues from carbon buildup in the intake manifold.
  • Subaru EJ20/FA20: Look for signs of wear on the injector seals; they can cause leaks.
  • Nissan VQ35/VK56: Wiring connectors near the exhaust can melt; inspect carefully.
  • Ram Cummins 6.7L diesel: Check for injector driver issues in the ECM.
  • Ford 6.7 Powerstroke: Be aware of injector harness issues due to heat exposure.

Parts and cost ranges

  • Fuel Injector: $60 - $150 each
  • Wiring Harness: $50 - $200
  • ECM: $150 - $800 (if needed)
  • Connector: $10 - $30
  • Labor: $75 - $150/hour

What people get wrong

  • Assuming the injector is faulty without checking wiring first.
  • Not checking for other related codes that could provide more insight.
  • Overlooking ground connections that could affect the injector circuit.
  • Ignoring the need for proper tools like a multimeter for accurate diagnosis.
  • Not using the Mobile Master Mechanic app for vehicle-specific troubleshooting.

Related codes

If you're facing this issue, you might also want to check codes like P0201, P0202, and P0203 for additional context.
