P0117: Don’t Ignore That ECT Sensor Circuit Low Input - It Can Leave You in a Lurch

Look - code P0117 is a warning that your Engine Coolant Temperature (ECT) sensor circuit is sending a low voltage signal. This can lead to a range of issues from poor fuel economy to overheating, and if you keep throwing parts at it without a solid diagnosis, you’ll end up frustrated and wallet-light. It’s essential to understand what you're dealing with before you start swapping out sensors.

Listen - while the ECT sensor itself is often the culprit, it’s not the only possible cause. Wiring issues, a failing engine control module (ECM), or even a bad ground can trigger this code. You need to check everything methodically instead of jumping at the first part you think is the problem.

Symptoms

  • Check Engine Light illuminated
  • Engine overheating or running too cool
  • Poor fuel economy
  • Rough idling or stalling
  • Delayed warm-up time
  • Failed emissions test due to incorrect readings
  • Erratic temperature gauge readings
  • Overcooling in cold weather conditions

Diagnostic order

  1. Check the ECT sensor connector for corrosion or damage.
  2. Measure the resistance of the ECT sensor at operating temperature; should be around 1,000 to 3,000 ohms.
  3. Inspect the wiring harness for shorts or breaks.
  4. Use a multimeter to test the voltage at the ECT sensor connector; should be between 0.5 to 4.5 volts.
  5. Check for any related codes in the OBD-II system.
  6. If everything checks out, consider testing the ECM for faults.

Common questions

  • What does the ECT sensor do?

    The ECT sensor measures the temperature of the engine coolant to help the ECM optimize engine performance.

  • Can I drive with code P0117?

    It’s not advisable. Driving with this code can lead to overheating and potential engine damage.

  • How much does it cost to replace the ECT sensor?

    Replacement costs can range from $30 to $150, depending on the vehicle.

  • What happens if I ignore this code?

    Ignoring it can lead to severe overheating, poor fuel economy, and can even cause long-term engine damage.

  • Can a bad thermostat trigger P0117?

    Yes, a stuck-open thermostat can cause the engine to run cooler than normal, triggering this code.

  • Is the ECT sensor the same as the coolant temperature gauge sensor?

    No, while they measure temperature, they serve different purposes and may not be interchangeable.

  • How can I clear the code?

    You can clear the code using an OBD-II scanner or by disconnecting the battery for several minutes.

  • Will replacing the ECT sensor fix the problem?

    Not necessarily; ensure you check the entire circuit before replacing the sensor.

Vehicle-specific notes

  • Ford EcoBoost engines (1.5/2.0/2.3/3.5L) often have ECT sensor failures due to heat exposure.
  • Honda K-series (2.0/2.4) can experience connector corrosion, affecting readings.
  • Toyota 2GR-FE V6 may have issues with the wiring harness, leading to intermittent failures.
  • GM 2.4 Ecotec models might show a false low signal due to a malfunctioning thermostat.
  • GM 3.6 LFX engines sometimes need a software update to address ECT sensor circuit issues.
  • Hyundai/Kia Theta II 2.0/2.4 GDI engines are prone to ECT sensor failures, particularly in older models.
  • BMW N20/N54/N55 can be sensitive to low coolant levels affecting the ECT sensor's performance.
  • Subaru EJ20/FA20 engines have been known to have wiring harness failures that lead to P0117.
  • Nissan VQ35/VK56 engines may trigger this code if the ECT sensor port is clogged.
  • Chrysler 3.6 Pentastar engines are often affected by bad ground connections.

Parts and cost ranges

  • ECT Sensor: $30 - $150
  • Wiring harness repair: $20 - $80
  • Thermostat: $30 - $120
  • Engine Control Module (ECM): $500 - $1,200

What people get wrong

  • Assuming the ECT sensor is always the problem without checking wiring.
  • Not considering other related components like the thermostat.
  • Clearing the code without taking any further action.
  • Ignoring poor connection issues that can cause intermittent failures.
  • Replacing parts without confirming the root cause through testing.

Related codes

Other OBD-II codes you might encounter include P0116 (ECT Sensor Range/Performance Problem) and P0118 (ECT Sensor Circuit High Input). Both codes can provide additional insight into your engine's temperature management system.
